Mitutoyo - Dial Test Indicator, Horizontal Type - 513-405-10T
SKU
513-405-10T
In stock
₹ 10,560.00
(Inc. GST)
Overview
Full Set, 0,2mm, 0,002mm, 4/8mm Stem, Styli, Bar, Swivel Clamp
Description
A Mitutoyo versatile anti-magnetic type lever indicator (or dial test indicator, DTI) suited to alignment operations on machine tools and similar applications. This indicator automatically adapts to the required measuring direction on contact, and the jewelled movement provides lowest friction and stiction for smooth and precise operation. Supplied with a comprehensive set of mounting accessories and interchangeable styli that enable immediate use in almost any situation.
Features
| Digital/Analog | Analog |
| Inch-Metric | Metric |
| Delivered | In a box with stem ø8/4 mm, stylus ø1/2/3 mm, swivel clamp / holding bar |
| Range | 0.2 mm |
| Dial reading | 0-100-0 |
| Graduation | 0.002 mm |
| MPE any 10 scale divisions | 2 µm |
| MPE any 1/2 revolution | 3 µm |
| H MPE (Hysteresis) | 2 µm |
| R MPE (Repeatability) | 1 µm |
| Measuring force | 0,01 - 0,3 N |
| Carbide stylus tip ø2 mm No | 103011 |
| Mass |
45 g
|
| Contact point |
Thread M 1.7 x 0.35
|
| Remarks |
Remarks
|
