Lutron - Vibration Meter - VB8201HA

SKU
VB8201HA
In stock
₹ 19,500.00 (Inc. GST)
Overview

Descriptions

Lutron VB8201HA Vibration Meter is a one-hand operating device and it is used to measure frequency and acceleration. This Vibration Meter comes with a complete set with a heavy-duty & compact housing case.



 Features of Lutron Vibration Meter:

  • This Lutron Vibration Meter measures Frequency range 10 Hz – 1 kHz and sensitivity relative meet ISO 2954.
  • Super large LCD screen
  • RMS & Peak measurement
  • Microcomputer circuit, high performance.
  • The Vibration Meter supplies with vibration sensor
  • This Lutron Vibration Meter has auto shut-off mode and it saves battery life.
  • It has a built-in low battery indicator.
  • Velocity measuring range 200 mm/s.
  • Heavy duty & compact housing case.
  • Acceleration measuring range 200 m/s2.
  • Complete set with the hard carrying case
  • Data hold button to freeze the desired reading



Specifications

Manufacturer Lutron
Model No VB8201HA
Measuring Parameters Acceleration, Frequency, Velocity
Operating Temperature Operating Temperature
Temperature Accuracy 23 ± 5 °C
Operating Humidity < 80% RH.
Measurement frequency 10 Hz to 1 KHz
Frequency Accuracy 80 Hz, 160 Hz
Circuit Exclusive microcomputer circuit
Display Large LCD Display
Power Supply DC 9V
Battery Alkaline
Power Consumption Approx. DC 6 mA
Memory Maximum & Minimum value.
Dimensions Main Instrument: 185 x 78 x 38 mm
Weight 274 Grams
